A, scope of application:
DJYVP, DJYPV, DJYPVP electronic computer with signal cable used to connect computer peripherals to the production site, as well as a variety of instrument electric equipment, automation equipment needed signal cable shielding type, such as used in electric power, chemical, petrochemical refinery, metallurgy, textile and other fields.
Second, the technical indicators:
Follow the standards of IEC189
Product features:
DJYVP, DJYPV, DJYPVP electronic computer with signal cable with small dielectric constant of the high pressure PE insulation and structure have on ground screen a total screen (or a set of three twisted shielding, combination screen group total shielding) with a small dielectric loss, transmit ability is strong, good anti-interference performance.
Four, the electronic computer with signal cable type and name:
model | The name of the | Scope of application |
| DJYVP | PE insulation total shield PVC sheathed computer with signal cable | Long-term working temperature signal cable - 20 ℃ ~ 70 ℃ ~ 20 ~ 105 ℃, laying temperature not lower than 0 ℃, the bending radius should not less than 6 times of cable diameter. |
| DJYPV | PE insulation to shield PVC sheathed electronic computer with signal cable | |
| DJYPVP | PE insulation on the screen to PVC sheathed computer with signal cable |
Note: 1, the wire core as A model, also can produce R type, type flame retardant (ZR), armoured (V22)
2, block: P: copper wire, P1: bottom tin copper wire, P2: copper strip, P3: ribbon, P4, aluminum-plastic composite belt
3, PD: on the screen, PJ: to the ground to the screen, JP: the ground total screen, PJP: on the ground to screen a total screen
Five, the specification
model | Nominal section (square centimeters) |
DJYVP | 0.5 0.75 1.0 1.5 2.5 |
DJYPV | |
DJPVP |
